Appendix A - Chart Installation ECDIS-E User Guide
A-6 65934012
2. When ARCS charts have been successfully installed, exit the
ChartHandler application as described previously.
NAVTOR Charts
Encrypted ENC charts (S-63) are provided by NAVTOR on CD, DVD or
USB memory stick (NavStick). The chart loading process uses the installed
cell permits to decrypt chart cells, verify the cells against the S-57 standard,
and compile them into SENC format used in VisionMaster.
NAVTOR charts and the NAVTOR security certificate must first be installed
onto the NavSync USB memory stick via a PC with Internet access.
Installing NAVTOR ENC chart files and chart permits is a procedure that
should be carried out on a weekly basis and is described below.
Installing NAVTOR Chart Permits
If you are receiving your NAVTOR ENC Charts on CD/DVD, the ENC cell
permits are included on the ENC PERMITS CD.
If you are using NAVTOR NavSync (NavStick) to update your ENC Charts,
the permit file(s) are located in `<NavStick>:\INFO\NAVTOR\PERMITS\’.
Both the CD and NavStick include separate folders for each system you
have ordered ENCs for. These folders are named ‘ECDIS 1’, ‘ECDIS 2’,
‘UNIT 3’, ‘UNIT 4’ and ‘UNIT 5’.
For example, if you have two ECDIS and one Chart Radar, the folders
‘ECDIS 1’, ‘ECDIS 2’ and ‘UNIT 3’ will be on the CD or NavStick.
CAUTION:
Do NOT install any other NAVTOR software on the NAVTOR NavStick
onto the VisionMaster nodes. This could have a detrimental effect on
your system
To install NAVTOR chart permits do the following:
1. Insert the ENC PERMITS CD into the CD drive, or the NavStick
into a USB drive on your ‘ECDIS 1’ PC.
2. Click on the Import ARCS/S57/S63 button in the Chart Installation
area of Chart Tools (see Chart Installation).
3. From the Chart Installation window tick the Import S57/S63 check
box. The VMFT closes and the SevenCs ChartHandler opens.
4. From the ChartHandler navigate to the permit file from the Settings
tab folder by selecting Scan local path and click the Browse
button.
