ECDIS-E User Guide Routes
65934012 8-43
Route Status
A summary of the active leg of a monitored route
is shown in the Route Status window. The
information in this window is also shown in the
Route tab folder of the Monitor Route sub menu.
The information in the Route Status window
includes the following:
Name The name of the route currently monitored.
Route
Progress
The state of ship on the route e.g. 'Sailing To WPT6 (6/7)'
denotes next waypoint on route and total number of
waypoints.
XTD
XTD (Cross Track Distance) is the off track distance on
either the Port side (PORT) or Starboard side (STBD) from
the monitored route.
DWOL Distance to go to the next wheelover leg.
TWOL Time to go along the leg to next wheelover based on
present ship speed
ETA Estimated Time of Arrival at the end of the route using own
ship SOG for this leg and planned speeds for future legs
(UTC or Local time).
