STC micro STC8A8K64D4 Series - Instruction Set

STC8A8K64D4 Series Manual
-
- 199 -
10 Instruction Set
Mnemonic
Description
Bytes
Cycle
ADD A,Rn
Add register to Accumulator
1
1
ADD A,direct
Add ditect byte to Accumulator
2
1
ADD A,@Ri
Add indirect RAM to Accumulator
1
1
ADD A,#data
Add immediate data to Accumulator
2
1
ADDC A,Rn
Add register to Accumulator with Carry
1
1
ADDC A,direct
Add ditect byte to Accumulator with Carry
2
1
ADDC A,@Ri
Add indirect RAM to Accumulator with Carry
1
1
ADDC A,#data
Add immediate data to Accumulator with Carry
2
1
SUBB A,Rn
Subtract Register from Accumulator with borrow
1
1
SUBB A,direct
Subtract direct byte from Accumulator with borrow
2
1
SUBB A,@Ri
Subtract indirect RAM from Accumulator with borrow
1
1
SUBB A,#data
Substract immediate data from Accumulator with borrow
2
1
INC A
Increment Accumulator
1
1
INC Rn
Increment register
1
1
INC direct
Increment direct byte
2
1
INC @Ri
Increment indirect RAM
1
1
DEC A
Decrement Accumulator
1
1
DEC Rn
Decrement Register
1
1
DEC direct
Decrement direct byte
2
1
DEC @Ri
Decrement indirect RAM
1
1
INC DPTR
Increment Data Pointer
1
1
MUL AB
Multiply A & B, high byte of result is in B, low byte in A
1
2
DIV AB
Divde A by B, quotient is in A, remainder is in B.
1
6
DA A
Decimal Adjust Accumulator
1
3
ANL A,Rn
AND Register to Accumulator
1
1
ANL A,direct
AND direct btye to Accumulator
2
1
ANL A,@Ri
AND indirect RAM to Accumulator
1
1
ANL A,#data
AND immediate data to Accumulator
2
1
ANL direct,A
AND Accumulator to direct byte
2
1
ANL direct,#data
AND immediate data to direct byte
3
1
ORL A,Rn
OR register to Accumulator
1
1
ORL A,direct
OR direct byte to Accumulator
2
1
ORL A,@Ri
OR indirect RAM to Accumulator
1
1
ORL A,#data
OR immediate data to Accumulator
2
1
ORL direct,A
OR Accumulator to direct byte
2
1
ORL direct,#data
OR immediate data to direct byte
3
1
XRL A,Rn
Exclusive-OR register to Accumulator
1
1
XRL A,direct
Exclusive-OR direct byte to Accumulator
2
1
XRL A,@Ri
Exclusive-OR indirect RAM to Accumulator
1
1
XRL A,#data
Exclusive-OR immediate data to Accumulator
2
1
XRL direct,A
Exclusive-OR Accumulator to direct byte
2
1
XRL direct,#data
Exclusive-OR immediate data to direct byte
3
1
