U8W/U8W-Mini and

User systems are independent

Power supply cable

U8W/U8W-Mini to

The user's system power supply

wiring

User system gives

U8W/U8W-Mini

Power supply cable

G.3.1 Install U8W/U8W-Mini driver

The U8W/U8W-Mini download board uses a CH340 USB-to-serial universal chip. This saves the trouble that some

computers without a serial port must buy a USB to serial port tool to download. But CH340 is the same as other USB-

to-serial tools, the driver must be installed before use.

Obtain the driver by downloading the STC-ISP software package

The following is the download location of the STC-ISP software package provided on the STC official website

(www.STCMCUDATA.com):

After downloading, decompress, the path of CH340 driver installation package is stc-isp-15xx-v6.87K\USB to UART

Driver\CH340_CH341:
