6.3.6 Traditional 8051 high voltage power-on reset reference circuit
Vcc
301R
Traditional 8051 reset pin
Traditional 8051 high voltage reset circuit
Optional
10uF
10K
The picture above shows the high-level reset circuit of the traditional 8051. The reset of the STC8A8K64D4 is a low-level
reset, which is different from the traditional reset circuit.
