STC micro STC8A8K64D4 Series - LCM Interface Data Registers (LCMIFDATL, LCMIFDATH)

To Next Page

To Previous Page

STC8A8K64D4 Series Manual

- 630 -

LCMIFSTA

FE53H

LCMIFIF

LCMIFIF: LCM interface interrupt request flag, needs to be cleared by software

22.2.5 LCM interface Data Registers (LCMIFDATL, LCMIFDATH)

Symbol

Address

LCMIFDATL

FE54H

LCMIFDAT[7:0]

LCMIFDATH

FE55H

LCMIFDAT[15:8]

LCMIFDAT: LCM interface data register

When the data width is 8 bits, only the LCMDATL data is valid.

When the data width is 16 bits, it is combined into 16-bit data by LCMDATL and LCMDATH.
