STC8A8K64D4 Series Manual

- 515 -

17.5.8 Reference circuit diagram for detecting negative voltage

+5V

10K

Test-IN

Negative Voltage Conversion Circuit

10K

Test-OUT

-5V~+5V

0～+5V，

which can be connected to

MCU AD detection port
