STC micro STC8A8K64D4 Series - Timer 1 (Mode 0 - 16-Bit Auto Reload)

STC8A8K64D4 Series Manual
- 308 -
MOV P5M1, #00H
MOV TMOD,#00H ;Mode 0
MOV TL0,#66H ;65536-11.0592M/12/1000
MOV TH0,#0FCH
SETB TR0 ;Start timer
MOV INTCLKO,#01H ;Enable clock output
JMP $
END
13.5.8 Timer 1 (Mode 0 - 16-bit auto reload)
C language code
//Operating frequency for test is 11.0592MHz
#include "reg51.h"
#include "intrins.h"
sfr P0M1 = 0x93;
sfr P0M0 = 0x94;
sfr P1M1 = 0x91;
sfr P1M0 = 0x92;
sfr P2M1 = 0x95;
sfr P2M0 = 0x96;
sfr P3M1 = 0xb1;
sfr P3M0 = 0xb2;
sfr P4M1 = 0xb3;
sfr P4M0 = 0xb4;
sfr P5M1 = 0xc9;
sfr P5M0 = 0xca;
sbit P10 = P1^0;
void TM1_Isr() interrupt 3
{
P10 = !P10; //Test port
}
void main()
{
P0M0 = 0x00;
P0M1 = 0x00;
P1M0 = 0x00;
P1M1 = 0x00;
P2M0 = 0x00;
P2M1 = 0x00;
P3M0 = 0x00;
P3M1 = 0x00;
P4M0 = 0x00;
P4M1 = 0x00;
P5M0 = 0x00;
P5M1 = 0x00;
