STC micro STC8A8K64D4 Series - Timer 1 (Mode 2) Is Used as Baud Rate Generator of UART1

STC8A8K64D4 Series Manual
- 323 -
MOV P2M1, #00H
MOV P3M0, #00H
MOV P3M1, #00H
MOV P4M0, #00H
MOV P4M1, #00H
MOV P5M0, #00H
MOV P5M1, #00H
LCALL UART_INIT
SETB ES
SETB EA
MOV DPTR,#STRING
LCALL UART_SENDSTR
LOOP:
MOV A,RPTR
XRL A,WPTR
ANL A,#0FH
JZ LOOP
MOV A,RPTR
ANL A,#0FH
ADD A,#BUFFER
MOV R0,A
MOV A,@R0
LCALL UART_SEND
INC RPTR
JMP LOOP
STRING: DB 'Uart Test !',0DH,0AH,00H
END
13.5.15 Timer 1 (Mode 2) is used as baud rate generator of UART1
C language code
//Operating frequency for test is 11.0592MHz
#include "reg51.h"
#include "intrins.h"
#define FOSC 11059200UL
#define BRT (256 - FOSC / 115200 / 32)
sfr AUXR = 0x8e;
sfr P0M1 = 0x93;
sfr P0M0 = 0x94;
sfr P1M1 = 0x91;
sfr P1M0 = 0x92;
sfr P2M1 = 0x95;
sfr P2M0 = 0x96;
sfr P3M1 = 0xb1;
sfr P3M0 = 0xb2;
sfr P4M1 = 0xb3;
