STC8A8K64D4 Series Manual
- 350 -
#define ET4 0x40
sfr AUXINTIF = 0xef;
#define T2IF 0x01
#define T3IF 0x02
#define T4IF 0x04
sfr P0M1 = 0x93;
sfr P0M0 = 0x94;
sfr P1M1 = 0x91;
sfr P1M0 = 0x92;
sfr P2M1 = 0x95;
sfr P2M0 = 0x96;
sfr P3M1 = 0xb1;
sfr P3M0 = 0xb2;
sfr P4M1 = 0xb3;
sfr P4M0 = 0xb4;
sfr P5M1 = 0xc9;
sfr P5M0 = 0xca;
sbit P10 = P1^0;
void TM3_Isr() interrupt 19
{
P10 = !P10; //Test port
}
void main()
{
P0M0 = 0x00;
P0M1 = 0x00;
P1M0 = 0x00;
P1M1 = 0x00;
P2M0 = 0x00;
P2M1 = 0x00;
P3M0 = 0x00;
P3M1 = 0x00;
P4M0 = 0x00;
P4M1 = 0x00;
P5M0 = 0x00;
P5M1 = 0x00;
T3L = 0x66; //65536-11.0592M/12/1000
T3H = 0xfc;
T4T3M = 0x08; //Start timer
IE2 = ET3; //Enable timer interrupt
EA = 1;
while (1);
}
Assembly code
;Operating frequency for test is 11.0592MHz
T4T3M DATA 0D1H
T4L DATA 0D3H
T4H DATA 0D2H
T3L DATA 0D5H
