STC8A8K64D4 Series Manual

- 385 -

Write

S3CON

RxD3

S3RI

D0 D1 D2 D3 D4 D5 D6 D7Start Stop

Receiving data (UART3 mode 1)

RB8

S3REN=1,S3RI=0

The baud rate calculation formula of UART3 mode 1 is exactly the same as that of mode 0. Please refer to the

mode 0 baud rate calculation formula.
