STC8A8K64D4 Series Manual

- 563 -

P_SW2 DATA 0BAH

PWMSET DATA 0F1H

PWMCFG DATA 0F6H

PWMCH EQU 0FF00H

PWMCL EQU 0FF01H

PWMCKS EQU 0FF02H

PWMTADCH EQU 0FF03H

PWMTADCL EQU 0FF04H

PWMIF EQU 0FF05H

PWMFDCR EQU 0FF06H

PWM0T1H EQU 0FF10H

PWM0T1L EQU 0FF11H

PWM0T2H EQU 0FF12H

PWM0T2L EQU 0FF13H

PWM0CR EQU 0FF14H

PWM0HLD EQU 0FF15H

ADC_CONTR DATA 0BCH

ADC_POWER EQU 080H

ADC_START EQU 040H

ADC_FLAG EQU 020H

ADC_EPWMT EQU 010H

ADC_RES DATA 0BDH

ADC_RESL DATA 0BEH

EADC BIT IE.5

P0M1 DATA 093H

P0M0 DATA 094H

P1M1 DATA 091H

P1M0 DATA 092H

P2M1 DATA 095H

P2M0 DATA 096H

P3M1 DATA 0B1H

P3M0 DATA 0B2H

P4M1 DATA 0B3H

P4M0 DATA 0B4H

P5M1 DATA 0C9H

P5M0 DATA 0CAH

ORG 0000H

LJMP MAIN

ORG 002BH

LJMP ADCISR

ORG 00B3H

LJMP PWM0ISR

ORG 0100H

ADCISR:

ANL ADC_CONTR,#NOT ADC_FLAG

RETI

PWM0ISR:

PUSH ACC

MOV A,PWMCFG
