STC8A8K64D4 Series Manual
- 604 -
P0 = RecvData(); //Read data 1
SendACK();
P2 = RecvData(); //Read data 2
SendNAK();
Stop(); //Send stop command
P_SW2 = 0x00;
while (1);
}
Assembly code
;Operating frequency for test is 11.0592MHz
P_SW2 DATA 0BAH
I2CCFG XDATA 0FE80H
I2CMSCR XDATA 0FE81H
I2CMSST XDATA 0FE82H
I2CSLCR XDATA 0FE83H
I2CSLST XDATA 0FE84H
I2CSLADR XDATA 0FE85H
I2CTXD XDATA 0FE86H
I2CRXD XDATA 0FE87H
SDA BIT P1.4
SCL BIT P1.5
P0M1 DATA 093H
P0M0 DATA 094H
P1M1 DATA 091H
P1M0 DATA 092H
P2M1 DATA 095H
P2M0 DATA 096H
P3M1 DATA 0B1H
P3M0 DATA 0B2H
P4M1 DATA 0B3H
P4M0 DATA 0B4H
P5M1 DATA 0C9H
P5M0 DATA 0CAH
ORG 0000H
LJMP MAIN
ORG 0100H
START:
MOV A,#00000001B ;Send START command
MOV DPTR,#I2CMSCR
MOVX @DPTR,A
JMP WAIT
SENDDATA:
MOV DPTR,#I2CTXD ;Write data to the data buffer
MOVX @DPTR,A
MOV A,#00000010B ;Send a SEND command
MOV DPTR,#I2CMSCR
MOVX @DPTR,A
JMP WAIT
