STC8A8K64D4 Series Manual

- 615 -

Assembly code

;Operating frequency for test is 11.0592MHz

P_SW2 DATA 0BAH

I2CCFG XDATA 0FE80H

I2CMSCR XDATA 0FE81H

I2CMSST XDATA 0FE82H

I2CSLCR XDATA 0FE83H

I2CSLST XDATA 0FE84H

I2CSLADR XDATA 0FE85H

I2CTXD XDATA 0FE86H

I2CRXD XDATA 0FE87H

SDA BIT P1.4

SCL BIT P1.5

ISDA BIT 20H.0 ;Device address flag

ISMA BIT 20H.1 ;Storage address flag

ADDR DATA 21H

P0M1 DATA 093H

P0M0 DATA 094H

P1M1 DATA 091H

P1M0 DATA 092H

P2M1 DATA 095H

P2M0 DATA 096H

P3M1 DATA 0B1H

P3M0 DATA 0B2H

P4M1 DATA 0B3H

P4M0 DATA 0B4H

P5M1 DATA 0C9H

P5M0 DATA 0CAH

ORG 0000H

LJMP MAIN

ORG 00C3H

LJMP I2CISR

ORG 0100H

I2CISR:

PUSH ACC

PUSH PSW

PUSH DPL

PUSH DPH

MOV DPTR,#I2CSLST ;Detect slave status

MOVX A,@DPTR

JB ACC.6,STARTIF

JB ACC.5,RXIF

JB ACC.4,TXIF

JB ACC.3,STOPIF

ISREXIT:

POP DPH

POP DPL

POP PSW

POP ACC
