STC8A8K64D4 Series Manual

- 55 -

CLKDIV: Frequency division factor of the main clock. The system clock SYSCLK is a clock signal obtained by dividing the

main clock MCLK.

CLKDIV

System clock frequency

MCLK/1

MCLK/2

MCLK/3

…

MCLK/x

…

255

MCLK/255
