STC8A8K64D4 Series Manual

- 83 -

_nop_();

while (1)

{

P11 = ~P11;

}

Assembly code

; Operating frequency for test is 11.0592MHz

T2L DATA 0D7H

T2H DATA 0D6H

T3L DATA 0D5H

T3H DATA 0D4H

T4L DATA 0D3H

T4H DATA 0D2H

T4T3M DATA 0D1H

AUXR DATA 8EH

IE2 DATA 0AFH

ET2 EQU 04H

ET3 EQU 20H

ET4 EQU 40H

AUXINTIF DATA 0EFH

T2IF EQU 01H

T3IF EQU 02H

T4IF EQU 04H

P0M1 DATA 093H

P0M0 DATA 094H

P1M1 DATA 091H

P1M0 DATA 092H

P2M1 DATA 095H

P2M0 DATA 096H

P3M1 DATA 0B1H

P3M0 DATA 0B2H

P4M1 DATA 0B3H

P4M0 DATA 0B4H

P5M1 DATA 0C9H

P5M0 DATA 0CAH

ORG 0000H

LJMP MAIN

ORG 000BH

LJMP TM0ISR

ORG 001BH

LJMP TM1ISR

ORG 0063H

LJMP TM2ISR

ORG 009BH

LJMP TM3ISR

ORG 00A3H

LJMP TM4ISR

ORG 0100H

TM0ISR:

CPL P1.0 ;Test port

RETI
