Adjusting knitting machine 4
Basic settings 4.1
106
4.1.1 Adjusting carriage speed
Different carriage speeds can be entered for different knitting situations.
The indirect carriage speed only becomes effective when it is slower than
the normal speed.
"Carriage speed" window
Explanation Value range
(meters/second)
MSECK Carriage speed for small knots over m
rows, standard: 1 row
Minimum value: 0.05
Maximum value: 1.20
Step width: 0.05
MSEC Speed
(normal speed)
Minimum value: 0.05
Maximum value: 1.20
Step width: 0.05
MSEC0 Speed for empty rows (S0) Minimum value: 0.05
Maximum value: 1.40
Step width: 0.05
MSEC1 Speed for transfer rows Minimum value: 0.05
Maximum value: 1.20
Step width: 0.05
MSECC Speed outside the needle bed when the
yarn carrier is brought in the clamp or taken
out of the clamp.
Minimum value: 0.05
Maximum value: 0.50
Step width: 0.05
MSEC2-20 Speed for knitting rows Minimum value: 0.05
Maximum value: 1.20
Step width: 0.05
Comment Comment ASCII Characters
