293
6 Maintenance of the knitting machine
6.3 Lubricate knitting machine
6.3.11 Greasing the linear guidance
If the lubricating interval for the linear guidance has elapsed, a pictograph
appears indicating that the linear guidance has to be greased.
1. Remove the carriage assembly panelling (1).
2. Grease the lubricating nipples (2) with a grease gun (Klueber Staburags
NBU 12/300 KP, ID 231 191)
IMPORTANT
An irreversible damage of the linear guidance is
possible!
In case of insufficient grease, there is the risk of damaging
the linear guidance.
➜ If the "Grease linear guidance" icon is displayed, the
linear guidance must be greased immediately.
