Stoll CMS ADF-3 - Greasing Impulse Sensor Rails

291
6 Maintenance of the knitting machine
6.3 Lubricate knitting machine
6.3.8 Greasing impulse sensor rails
Depending on the machine gauge, there is a front and a rear impulse sensor
rail.

Greasing the impulse sensor rails
➜ Use a brush to apply grease to the impulse giver rails (1).
Machine gauge Impulse sensor rail
E18 (E9.2)
E16 (E8.2)
E14 (E7.2)
E12 (E6.2)
E10 (E5.2)
at the front and at the rear
E8
E7 (E3,5.2)
E5 (E2,5.2)
E4
E3.5
E3
rear
