Stoll CMS ADF-3 - Comparing Setup1 to Setup2

235
5 Setup Data
5.2 Comparing Setup1 to Setup2
5.2 Comparing Setup1 to Setup2
Setup1 Setup2
Fabric take-down
functions (WMF)
8 functions 50 fabric take-down
functions (WMF)
50 Auxiliary take-down
functions (W+F)
Switching auxiliary take-
down on and off (W+1,
W+0)
Tabs for WM% and
WMK%
Yarn Carrier Staggering
YD
One staggering (YD) 21 staggerings 
(YD, YDI1-YDI20)
Yarn carrier corrections One correction 20 corrections
(YCI1-YCI20)
Some corrections for all
32 yarn carriers can be
defined with each
function.
 The Setup file does not
contain the correction
of the normal yarn
carriers.
 Correction of Intarsia
yarn carrier in the KI /
K<I> tab
All yarn carrier corrections
(normal and intarsia) are
part of the YCI tab
with tandem operation: 
the correction values for
the right carriage are part
of the Y:Oa-b tab
Correction values for
stitch cam position (NP)
100 100
Specifications for the
carriage speed (MSEC)
920
Correction value for
clamping depth (NCC)
no part of the setup-file A correction value per
yarn carrier is possible
Yarn length Indications for yarn length
control on the right
Indications for yarn length
control on the right and left
Cycle Counters no indications possible 39 cycle counters
Racking Corrections VKA to VKZ, no part of the
setup-file
50 Indices for racking
corrections (VCI)
Comments no indications possible for each indication
possible
