Stoll CMS ADF-3 - Adjust Yarn Carrier Vertically

Adjusting knitting machine 4
Advanced adjustments 4.2
184
4.2.17 Adjust yarn carrier vertically
1. Call up the "Service" menu from the "Main menu".
2. Call up the "Adjustment of yarn carriers" window.
 The "Adjustment of yarn carriers" window appears.
3. In the "Adjustment" field set the switch to "Vertically".
4. The setting window appears.
5. In the " Correction value" field enter the desired height.
Value range: -2.5...0...2.5. Default = 0. Step width: 0.05 mm
Key Function
Call up the "Service" menu
Call up the "Adjustment of yarn carriers" window
Keys for calling up the "Adjustment of yarn carriers"
