Stoll CMS ADF-3 - Cleaning Main Drive Fan; Cleaning Fan and Radiators in Right Control Unit

Maintenance of the knitting machine 6
Cleaning the knitting machine 6.2
280
6.2.7 Cleaning main drive fan
1. Switch off the machine and wait until the machine is currentless.
2. Swing open the cover on the right-hand control unit.

Main drive fan
3. Clean fan.
4. Close the cover on the right control unit.
5. Switch on machine.
6.2.8 Cleaning fan and radiators in right control unit
1. Switch off the machine and wait until the machine is currentless.
2. Swing open the cover on the right-hand control unit.

Control unit
3. Vacuum-off and blow-out the fan (1) and heat sink (2).
4. Close the cover on the right control unit.
5. Switch on machine.
The control checks the motor temperature when switching on
machine main switch. The fan only runs at higher motor
temperature.
The fan is temperature-controlled.
