9 Yarns and stitch tension
9.2 Stitch Tension Range
9.2 Stitch Tension Range
The tension ranges for knitting and splitting differ. The reason for this is the
shape of the split-stitch piece. The information in the table show the
minimum and maximum NP values.
Further information:
 Economic production and the influencing factors [-> 411]
Valid for:
CMS 933
CMS 822
CMS 530
CMS 520
CMS ADF-3
min. NP max. NP min. NP (Split) max. NP (Split)
E 3 7.0 16.7 8.2 15.6
E 3,5 7.0 16.7 8.2 15.6
E 4 7.0 16.7 8.2 15.6
E 5 6.5 16.9 8.0 14.1
E 7 8.3 18.7 9.8 15.9
E 8 8.8 19.5 10.3 16.6
E 10 7.25 19.2 9.3 17.65
E 12 7.55 20.0 8.4 16.2
E 14 7.95 20.7 8.8 16.85
E 16 7.6 21.9 8.9 17.85
E 18 7.6 21.9 8.9 17.85
E 5.2 7.8 17.5 9.0 14.7
E 6.2 7.55 20.0 8.4 16.2
E 7.2 7.95 20.7 8.8 16.85
E 8.2 8.0 22.3 9.3 18.25
E 9.2 8.0 22.3 9.3 18.25
E 2,5.2 6.5 16.9 8.0 14.1
E 2,5.2
m.4L
6.5 16.9 8.0 16.15
E 3,5.2 8.3 18.7 9.8 15.9
E 3,5.2
m.4L
8.3 18.7 9.8 17.95
