Setup Data 5
Setup1 - Editing the setup file 5.5
266
5.5 Setup1 - Editing the setup file
The Setup data editor allows setup data to be edited without loading them
into the machine beforehand. It is thus possible to edit another setup file
while the machine is knitting a pattern. Each group of setup data has its own
tab with the corresponding input fields in the "Setup data editor" window.
The following events can prevent a correct saving of setup data:
The setup file is write protected.
This is displayed by a touch. The write protection can be deactivated by
the additional function key "Deactivate write protection".
Limiting values do not agree with each other.
The limiting values of the entered setup data are compared to data of
current machine and checked.
Conflicts may therefore arise if a setup file of a different machine is
being edited on the machine.
The tabs "NP1..50", "NP51..100", "WMF" and "MSEC" can contain
empty input fields.
This is because of the M1 that only deposits the used NP, WMF and
MSEC data into setup file.
When saving data from setup data editor, only the used NP, WMF and
MSEC data are also saved in setup file.
If no STIXX device is connected to the machine, the "STIXX"
and "STIXX3" tabs are not displayed although the setup file
contains STIXX data.
The STIXX data cannot be edited.
If the set-up data are saved, then existing STIXX data (not
displayed) are also saved.
