7 Repairing the knitting machine
7.3 Replacing parts
7.3.2 Replacing intermediate slider
There are different models depending on the gauge.
Type 1
To replace the intermediate slider, you need a small pair of pliers.

Replacing the intermediate slider
1. Push the needle and coupling part (1) upward.
2. Using the pliers, pull the lower butt of the intermediate slider (2)
downwards out of the needle bed while pressing the upper butt into the
needle bed and pressing it under the cover rail (3).
3. Install the new intermediate slider in the reverse order.
4. Slide the needle and coupling part into the home position.
Valid for:
E10 │ E12 │ E14 │ E16 │ E18 │ E6.2 │ E7.2 │ E8.2
