Repairing the knitting machine 7
Supplementary activities during maintenance 7.1
302
7.1.5 Sliding board
The sliding board consists of two individual boards. Each sliding board can
be pushed to the left or to the right.
A The sliding boards are secured at three points. Use the square spanner from
the accessories for opening.
B Each sliding board can be pushed to the left or to the right.
To be able to remove rear carriage part from the machine, push both sliding
boards into the same direction.
