5 Setup Data
5.4 Setup2 Editor
5.4.8 Racking
The racking instructions are valid for one carriage stroke.
Further information:
Table Tools [-> 244]
Helpers for Input [-> 239]
File tools [-> 245]
Overview of the Setup2 Editor of the CMS [-> 237]
Setup Data [-> 233]
Comparing Setup1 to Setup2 [-> 235]
Explanation Value range
VCI… Racking function VCI1 to VCI50
VK Racking correction by m steps (0-10) Step width: 1/70 of
the needle distance
Dir Direction of the racking correction
< - to the left
> - to the right
? - not defined, will be defined on the
machine
VV Racking speed n (1-32), without an
instruction VV=32
V+/- V+ - Overracking, in addition to the racking
specification
positive value: Overracking in racking
direction
negative value: Overracking in opposite to
the racking direction
(n=1-24, step width:
1/8 of the needle
distance)
Comment Comment ASCII Characters
