8 Software - Installation and basic settings
8.4 Installing the Stoll operating system
8.4.7 Overview of all system data
All important hardware and software data of the control are displayed in the
"System info" window.
"System info" window
Field Data shown
1 Stoll operating system (OS) that is loaded, the machine number, machine
type, gauge, yarn carrier type, etc.
2 "Memory" line: Display of the amount of memory this pattern occupies
3 Hardware and software data
Network data
Key Function
Call up the "Service" window
Call up "Diagnostics" window
Call up the "System info" window
Call up "Main menu"
Keys for calling up the "System info" window
