Stoll CMS ADF-3 - Take-Down

Setup Data 5
Setup2 Editor 5.4
246
5.4.2 Take-down
WMF (tab)
Explanation Value range
WMF… Fabric take-down function WMF1 to WMF50
WM min Minimum fabric take-down value
(with Fully Fashion)
Minimum value: 0
Maximum value: 31.5
Step width: 0.1
WM max Maximum fabric take-down value 
(value must always be specified)
Minimum value: 0
Maximum value: 31.5
Step width: 0.1
N min Minimum quantity of needles
(with Fully Fashion)
Minimum value: 0
Maximum value: Needle
number of the CMS
Step width: 1
N max Maximum quantity of needles
(with Fully Fashion)
Minimum value: 0
Maximum value: Needle
number of the CMS
Step width: 1
WMI Fabric take-down impulse Minimum value: 0
Maximum value: 15
Step width: 1
WM^ Open the brake of the active take-down
system (main take-down or comb take-
down) for a maximum of 2.5 seconds,
take-down roller or comb take-down turn
back by a maximum number of the
indicated degrees (depending on the
fabric tension and the fabric take-down
value).
CMS 5xx, 7xx, 8xx: 9-60 degrees
CMS 9xx: 9-120 degrees
If either of both the conditions is fulfilled,
then the brake is closed again.
Fabric take-down value (n=0-31.5)
becomes active again at the reversion.
No turning back: 0
Minimum value: 9
Maximum value: 120
Step width: 1
WMC Set the speed control of the active take-
down system (main take-down or comb
take-down) to the value n (0-32). If the
take-down system turns too quickly, the
machine is stopped.
0= no stop motion, 1= insensitive, 32=
very sensitive
Minimum value: 0
Maximum value: 32
Step width: 1
