Repairing the knitting machine 7
Supplementary activities during maintenance 7.1
300
7.1.3 Separating the suction tubes from the carriage
1. Remove the carriage assembly panelling (1).
2. Loosen the screw (3) and swivel the retainer downwards.
3. Lift the suction tube somewhat at the lower end (4). Push the suction
tube upwards until the fixing clip (5) is pulled out of the carriage.
