Adjusting knitting machine 4
Working with files 4.3
208
4.3.7 Selecting the current folder
General information Pattern files can be saved to various drives (memory locations) of the
knitting machine or to another computer on the network.
To load a file into the knitting machine from another drive, the entire path
must be specified. By path, we mean the specification of where the file is
located, for example on a drive of the M1 pattern workstation.
A path contains the following information:
1. Drive letter (or computer name) (e. g.: "D:" or "\\SERVER01")
2. Specification of the subdirectories (e. g.: "\PATTERN" or
"Stoll\M1\Extract\")
Standard setting Following drives are set by default in the keys of "Direct folder selection":
Selecting the current folder The selection of the patterns from the "Load & save" window is applied in
the "Catalog order data ", "Catalog Sequence data" and "Catalog Sequence
lists" windows.
(Exception: The specification in the "Copying catalog" window is only
effective for this window.)
Using the "Select current folder" key, you specify the drive to which the 3
"Direct folder selection" keys are linked.
Key Drive Explanation
F:\ USB Memory Stick
D:\ Hard disk
Name:\ Network drive
Standard settings of the drives
