Adjusting knitting machine 4
Advanced adjustments 4.2
164
4.2.9 Adjusting racking position correction VPK
The fine adjustment of the transfer racking is carried out by means of the
VPK value. With the "Racking position correction (VPK)" the rear needle
bed is aligned exactly relative to the front needle bed.
The VPK value always remains saved, even if the operating system is
imported again.
Adjusting VPK:
1. Program an empty row with transfer racking and fix the knitting
specification [ 303].
2. Push up two opposing needles in the center of the needle bed.
3. Check whether the needle hook of the front needle dips into the pelerine
spring of the rear needle.
4. If this is not the case: Push back needles and correct racking device.
5. Call up "Main menu".
6. Call up the "Service" menu.
Key Function
Call up the "Service" menu
Call up the "Service Racking" window
Confirm input
Call up "Main menu"
Keys for setting VPK value
