Stoll CMS ADF-3 - Moving Yarn Carriers and Repositioning Them

Producing with the knitting machine 3
Threading up yarn 3.2
72
3.2.5 Moving yarn carriers and repositioning them
For threading up and for repair work it is necessary to move the yarn carrier
out of the knitting area.
Moving yarn carriers
manually
1. Open the covers.
 All the yarn carriers are automatically disconnected from the power
supply - they are manually movable.
2. Move the yarn carrier to a position where it is as accessible as possible
and where it can be threaded it up easier.
Reposition the yarn carriers 1. Insert the thread in the needles.
2. Close the covers.
3. Confirm the error message.
4. Pull up the engaging rod.
 The yarn carriers move automatically back into their knitting
position.
Our recommendation:
Move the yarn carrier to a position where it is as accessible
as possible and where you can thread it up easier. For
example outside the knitting area or between the needle bed
and the clamping and cutting bed.
