9 Yarns and stitch tension
9.4 Yarn table
9.4 Yarn table
The specified values serve as a guideline. The quality and the specific
weight of a yarn must also be taken into account. Instead of a simple yarn,
we recommend twisted yarn. With coarser machines it is advisable to use
several twisted threads.
Further information:
Economic production and the influencing factors [-> 411]
Gauge assembled processing
[Nm]
Final count [Nm]
Several fine threads are
assembled and fed as a
thick yarn to the yarn carrier.
Yarn thickness of the
assembled threads
Example: 6 x 16/2
16/2=8
8:6=1,33
2 6 x 16/2 1,2 - 1,4
2.5 6 x 18/2 1,3 - 1,6
3 5 x 18/2 1 - 2
3 m.3L 15 x 20/2 0,65 - 1
3.5 6 x 24/2 1,4 - 2,5
4 5 x 24/2
6 x 34/2
1,4 - 3
5 4 x 24/2
4 x 34/2
3 - 4,5
7 2 x 22/2
2 x 28/2
4,5 - 7
8 2 x 24/2
2 x 34/2
6 - 8
10 2 x 36/2
1 x 24/2
8 - 12
12 1 x 24/2
2 x 44/2
10 - 18
14 1 x 28/2
2 x 40/1
14 - 20
Yarn table - Allocation of machine gauge and yarn thickness (Table 1)
