Description of knitting machine 2
Components of the knitting machine 2.1
22
Further information:
Symbols in this document [-> 14]
6 Control Unit
(CMS 530, CMS 520, CMS 520 C,
CMS 502)
It controls the knitting process.
It saves the data of the knitting
program.
It controls the needle selection and
the motors in the carriage.
Control (right-hand side of the
machine)
(CMS 830 C, CMS 822, CMS 740)
It controls the carriage run and the
racking of the needle bed.
7 Main drive The carriage is driven by the drive
motor via a toothed belt.
8 Racking device Racks the rear needle bed laterally.
Label Explanation
Overview machine elements 5
