Repairing the knitting machine 7
Eliminating faults in electronics system 7.4
346
Left control cabinet
Left control cabinet
Card Function
013
(ID 301 013)
Controlling the motors for the yarn carriers.
Each card controls 4 yarn carrier drives (servo motors) and 4 high/
low motors (step motors).
015
(ID 301 015)
Power supply of the motors for the yarn carriers.
Electronic cards
