Software - Installation and basic settings 8
Boot process 8.1
374
Configuring network If you wish to connect the knitting machine with another knitting machine or
a pattern unit, you must set up and switch on the network on the knitting
machine. The "Network Configuration" window is used for it.
➜ Tap on the "Configure Network" key.
The "Network Configuration" window is displayed.
"Network Configuration" window
In this window all the necessary network parameters are entered. The
values are entered with the internal keyboard (virtual keyboard) or with an
external keyboard.
Label Description
Computer Name The input of a (machine) name is necessary in order to enable
the other network users an access to this machine. This
machine is identified with this name in the network. Enter
descriptions of this machine in the "Description" field.
Workgroup All knitting machines should be located in the same
"Workgroup" so that the machines can communicate with
each other. This input field must be filled up. Ask for your
corresponding Work group name from your Network
administrator in case of a network spanning your firm/LAN.
Description The input of a description is optional, but it helps in identifying
a machine better in larger networks, e. g. Machine type,
gauge and other specifications of this machine . This input
appears as a comment in the Windows Explorer.
My Network Here are listed the computers that have been defined in "My
Network" field, see
KnitLAN connection [ 220].
If you wish to supplement the lists manually, take note of the
spelling when multiple computers are used:
\\computer name;\\computer name;\\computer name
As a separator between the individual computers the
semicolon (";") must be used.
Components of the "Network Configuration" window
