Producing with the knitting machine 3
Production 3.3
92
Stopping the running time:
✔ A pattern file has to be loaded (1).
1. If necessary set display with "Reset" at 0.
2. Tap on "Start".
In the "Running time" (2) field time that has passed since "Start" was
activated is shown in the format hh:mm.ss.
3. Starting the knitting process.
4. After the knitting process has been completed, tap"Stop".
The stopped time is displayed in the "Running time" (2) field.
Further information:
Carrying out restart with machine configuration (Restart and
Configuration) [-> 403]
Key Function
Call up the "Service" window
Call up "Statistics" window
Call up "Measurement of running time" window
Start measurement of running time (start)
Stop measurement of running time (Stop)
Set display at 0 (Reset)
Call up the "Main menu"
Keys for the "Measurement of running time" window
