6.1.1.9 Input Groups
The labels and contents of all eight input signal groups are cleared. If logical
inputs are detected, new input groups are initialized as follows:
• MIC, containing all logical inputs mapped to Mic/Line input cards
• LINE, containing all logical inputs mapped to Line input cards
• AES/EBU, containing all logical inputs mapped to AES/EBU I/O cards
• * ADAT, containing all logical inputs mapped to ADAT I/O cards
• * TDIF, containing all logical inputs mapped to TDIF I/O cards
• MADI, containing all logical inputs mapped to MADI I/O cards
• ** SDI, containing all logical inputs mapped to SDI I/O cards
. • ** Dolby E, containing all logical inputs mapped to Dolby E input cards.
* OnAir 2500: In external I/O frame only. ** OnAir 3000 only.
Patch Groups remain untouched by auto conguration.
In Addition: Insert points, input routing selections, output routing selections, and input
group selections are cleared and initialized as follows:
• Insert points: All new input groups are assigned together with the master
inserts
• Input and output routing: All new input groups are assigned together with
the master outputs
• Input group 1...8 selections: All new input groups are assigned.
6.1.1.10 Output Group
The logical outputs selection is cleared, and all logical outputs that are mapped
to any of the output cards will be added then.
