Studer OnAir 2500 User Manual

OnAir 2500/OnAir 3000 Digital Mixing Consoles
6-80 Conguration
Date printed: 22.07.08
SW V3.0
OnAir 2500/OnAir 3000 Digital Mixing Consoles
Conguration 6-81
Date printed: 22.07.08
SW V3.0
6.5.32.2 Rotary Assign 2 - Group 2 (supported by OnAir 3000 only)
This page is used to assign functions to the 16 rotary assign keys of the OnAir
3000’s optional rotary assign module(s), see below.With these keys the user
can then select the functions of the rotary encoders of the optional rotary
modules that are usually installed above the fader strips.
AUX1
AUX2
AUX3
AUX4
1
3
2
4
5
7
6
8
9
11
10
12
13
15
14
16
