OnAir 2500 Digital Mixing Console
Operation 5-5
Date printed: 18.07.08
SW V3.0
5.3.3 Channel Pages
There are two ways to open the channel page and to automatically select the
corresponding channel: Touching the Chan field in the main menu or press-
ing one of the direct access keys in the channel strip. The channel page pops
up and displays the selected channel functions.
In the lower line of the menu bar, the icons represent the current values.
Touching a menu icon opens the corresponding channel page.
Channel Selection: The channel label is indicated in the upper right corner of the page. With the
right and left arrow buttons on both sides of the channel label it is possible to
scroll the channel up and down. Touching the channel label opens the channel
list box where a channel can be directly selected.
5.3.3.1 (Channel) Input Page
The channel input page is divided into two sections. The left part shows the
parameters of the currently assigned active input (the picture is somewhat
depending on the input type – the following screenshots show analog or
digital stereo inputs), whereas in the right (GEN) part the test generator can
be activated if the current user has been given appropriate access rights.
Functions Common to All Input Types
Input Selection Assigning another audio input to the current fader channel is easily done by
touching the Input Selection button, selecting an audio input group from
the MIC/LINE... input group list box, and then selecting an audio input from
the input list box, as shown below.
