OnAir 2500 Digital Mixing Console
Operation 5-29
Date printed: 18.07.08
SW V3.0
PP / AP For input channels, the insert point can be set to either before (PP) or after
(AP) the signal processing (EQ/compressor for groups, limiter for masters).
5.3.6.4 (Routing) Mic Group Page
For ease of control, microphones may be grouped in Mic Groups. All mi-
crophones within the same group may be switched on/off with one single,
external Mic key (via a GP input).
Mic / POS The microphone is selected with the rotary encoder below the Mic field, the
mic group with the one below the POS field.
Assign / Clear Assignment of the selected microphone and group is done by touching
Assign; then a green bullet appears at the selected position. A touch on
Clear clears the selected assignment.
In the example above, the DJ mic and the guest mic #1 are assigned to mic
group 1, and the guest mic #2 is assigned to mic group 2; guest mic #3 is ready
to be assigned to mic group 2 – just touch Assign.
