OnAir 2500: OnAir 2500 only supports stereo metering outputs. These are congurable
for the OnAir 2500 too, but will not be used by default.
6.5.5 Insert Sends
For each of the eight inserts available in the digital domain, a send/return pair
may be congured. For the insert sends, the same applies as is said in chapter
6.5.2 above, except that no Format parameter is available here.
The insert returns are congured on the Insert Returns page (refer to chapter
6.5.6).
