UserSnapshot: Loading Input ChannelOnOff
If set to Off, the user snapshots do not contain the channel ON/OFF settings;
i.e. when loading a user snapshot, the channel ON/OFF settings remain as
they are. If set to On, the channel ON/OFF settings are saved with the user
snapshot and become updated when the snapshot is loaded to the console.
6.5.25 TalkBack
6.5.25.1 Settings
In contrast to the studios, the control room features only one dedicated input
for talkback to the studios. If this should not be sufcient, up to four physical
inputs (CR Mic 1...4) may be dened for use as alternate talkback sources
to the studios, such as the DJ mic, a Headset mic, etc. Only one of these four
may be active at a time.
Basic Label The basic label may be entered here as described in chapter 6.5.1.
Router Source Denes the physical audio input that is used to establish the mono channel
for the logical input.
Indication: Frame (Int = internal I/O cards in SCore frame; Ext # = additional,
external D21m frames), Slot #, Card type, and Input # (e.g. Int, Slot 11,
ADAT, Ch. 1), or “-” (if no physical input is assigned to the logical input).
Note: In order to select these physical talkback microphone inputs in the control
room talkback sources, one desk key must be congured for each of them (in
the Desk_KeyMapping.xml le).
