Studer OnAir 2500 User Manual

OnAir 2500/OnAir 3000 Digital Mixing Consoles
6-52 Conguration
Date printed: 22.07.08
SW V3.0
OnAir 2500/OnAir 3000 Digital Mixing Consoles
Conguration 6-53
Date printed: 22.07.08
SW V3.0
6.5.23 Signaling
6.5.23.1 Settings
OnAir Mode Selects the condition for switching the ON AIR light on: Internal (i.e., when
at least one channel fader is open, this channel is ON, assigned to a master
output, this master is dened to be OnAir Relevant - see chapter 6.5.11 - and
the master fader is open), External (i.e., when an external on-air input on
the GPI interface is active), or Internal AND External (i.e., a logical AND
operation of both conditions).
