Xerox 8825 Service Manual

01/02
4-57
8825/8830 Printer
REP 9.5
Repairs and Adjustments
2. (Figure 4): Reinstall the Toner Cartridge. 3. If new Developer Material has been installed, perform the Toner Sensor Calibration Code
[09216].
Figure 4 Reinstalling the Toner Cartridge
4
Slide the Top Shield
closed
3
Remove the tape
2
Partially rotate the
Toner Cartridge in
both directions to
ensure that the car-
tridge is locked in
the Drive Hub
1
Pull the plunger and
then reinstall the
Toner Cartridge
