Xerox 8825 Service Manual

01/02
1-9
8825/8830 Printer
Status Code Entry Chart
Service Call Procedures
E6-00 Front door interlock switch
error
The C button was pressed
while a print was being made
in the roll feed mode. An oper-
ator induced soft shutdown
results in a complete print
being made. The left side door
must be opened and then
closed.
Instruct the customer as
to the appropriate time to
press “C”
E6-01 Front door interlock switch
error
The Exit button was pressed
while a print was being made
in the roll feed mode. An oper-
ator-induced hard shutdown
results in a partial print being
made. The left side door must
be opened and then closed.
Instruct the customer as
to the appropriate time to
press “Exit”
E7-01 Communication error
The IOT is unable to commu-
nicate with the Controller. The
IOT Off-Line and Media
menus will still function, but
cannot print from the Control-
ler or network.
Go to E701 RAP in 8830
Controller Service Man-
ual.
E7-02
No
RAP
Printer message display
error
A required message is not
available in the language
EPROM. Update the lan-
guage EPROM.
Language EPROM BSD
2.1
E9-XX Software shutdown
This error is of unknown
cause. Please contact Soft-
ware engineering.
Fx-xx Refer to the Folder Service
Manual for all F-codes.
J1-01
No
RAP
Toner sensor error
Out of toner.
Toner sensor (A22Q1)
Main PWB (A3)
BSD
9.7
PL
9.9
PL
1.1A
Table 1 Status Code Entry Chart
Status
Code
Description Components BSD
Ref
PL
Ref
J2-02
No
RAP
Cartridge home sensor
error
Toner cartridge could not find
the home position.
Cartridge Home Sensor
(A22Q2)
Main PWB (A3)
Cartridge Drive Motor
Cartridge Drive Gear
BSD
9.7
PL
9.9
PL
1.1A
PL
9.10
LL-00 Communication error
Applies only to printers with a
bit mapped user interface
(FX).
LL-02 Check sum test error
Both message ROMs have
failed the checksum test
immediately after power up.
LL-05
No
RAP
Fuser oil web error
NVM count of web encoder
pulses indicates the fuser oil
web has reached end of life.
Web oiler motor
(A23MOT1)
Driver PWB (A2)
CONTROL EPROMS
BSD
10.2
PL
1.1A
PL
9.6
LL-06
No
RAP
Fuser oil web error
No encoder pulses are being
received from the fuser oil
web.
Web oiler optical switch
(A23S2)
Web oiler motor
(A23MOT1)
Driver PWB (A2)
BSD
10.2
PL
1.1A
PL
9.6
LL-07
No
RAP
Fuser oil web error
Web Oiler Assembly connec-
tor not connected.
P/J 4, wiring harness,
pins
Driver PWB (A2)
NOTE: TAG 3 must be
installed for this code.
If not, disable the fault
detection using [10-35
BSD
10.2
PL
10.4
PL
1.1A
LL-10
No
RAP
Module wrap-around error
The paper transport assem-
bly or the Xerographic module
is disconnected.
Xerographic module
(A23)
Paper transport assem-
bly (A21)
Driver PWB (A2)
BSD
7.5
PL
1.1A
LL-11
No
RAP
Communications error
Failed communications
between the Driver PWB (A2)
and the Main PWB (A3).
Driver PWB (A2) (fuser
drive circuit)
Driver PWB (A2) (drum
drive circuit)
Main PWB (A3)
CAUTION: Fuser must
be up to temperature
before running motors.
BSD
4.1
BSD
4.3
PL
1.1A
Table 1 Status Code Entry Chart
Status
Code
Description Components BSD
Ref
PL
Ref
