01/02
6-45
8825/8830 Printer
Removal Procedure
General Procedures
Figure 4 Installing the Cable Tie
1
Lift Stripper Bar slightly
2
Install a cable tie
3
Allow bar to return to normal
position
Fuser Heat Roll
