3.10 Fine Tuning during Test Runs (Adjust the Control Function)
210 YASKAWA ELECTRIC SIEP C710617 05F YASKAWA AC Drive GA700 Technical Manual
Issue Parameter Number Solution Default Setting Recommended Setting
• Torque or speed
response are slow.
• Hunting or oscillation
• High speed
C5-01 [ASR
Proportional Gain 1
(P)]
• Low speed
C5-03 [ASR
Proportional Gain 2
(P)]
*3
• If torque or speed
response are slow,
increase the setting
value in increments of
5.00.
• If hunting or oscillation
occur, decrease the
setting value.
20.00 10.00 - 50.00
• High speed
C5-02 [ASR Integral
Time 1 (I)]
• Low speed
C5-04 [ASR
Proportional Gain 2
(P)]
*3
• If torque or speed
response are slow,
decrease the setting
value.
• If hunting or oscillation
occur, increase the
setting value.
0.500 s 0.300 to 1.000 s
The drive cannot find
speed response for low
speed or high speed.
• C5-07 [ASR Gain
Switchover Frequency]
*4
• High speed
C5-01 [ASR
Proportional Gain 1
(P)]
C5-02 [ASR Integral
Time 1 (I)]
• Low speed
C5-03 [ASR
Proportional Gain 2
(P)]
*3
C5-04 [ASR Integral
Time 2 (I)]
Change the ASR
proportional gain and
ASR integral time to
conform to the output
frequency.
0.0 Hz
0.0 to maximum output
frequency
Hunting or oscillation
C5-06 [ASR Delay Time]
*4
• If torque or speed
response are slow,
decrease the setting
value in increments of
0.010.
• If the rigidity of the
machine is
unsatisfactory and
vibration is possible,
increase the setting
value.
0.004 s 0.004 to 0.020 s
*1 Default value changes when o2-04 [Drive Model (KVA) Selection] and C6-01 [Normal / Heavy Duty Selection] values change.
*2 Default value changes when o2-04 [Drive Model (KVA) Selection] value changes.
*3 Refer to the section on C5-xx parameters for more information about speed control (ASR).
*4 The best values for a no-load operation are different than the best values for actual loading operation.
