Zebra ZM400 Series

Corrective Maintenance
220
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
4. See Figure 90. Pull the top of the power supply shield away from the main frame and fold
it down to access the stepper motor connector.
Figure 90 • Gain Access the Power Supply
1
Power supply shield
1
